ASUS ZenWiFi AX (XT9) AX7800 Mesh Wi-Fi 6 System Tri-Band Whole-Home - White

ASUS ZenWiFi AX (XT9) AX7800 Mesh Wi-Fi 6 System Tri-Band Whole-Home - White

Superior Whole-Home Wi-Fi

The ASUS ZenWiFi AX (XT9) delivers robust and reliable Wi-Fi coverage across your entire home.

With its mesh network technology, it ensures a stable and seamless connection, even in larger homes or areas with Wi-Fi dead zones.

Support 160MHz Channel

This system supports the 160MHz channel width, allowing for faster and more efficient internet speeds, making it ideal for bandwidth-heavy tasks such as 4K streaming, gaming, and large file transfers.

Expanded UNII-4 Spectrum

The XT9 is equipped with the expanded UNII-4 spectrum, providing a more stable and less congested connection.

This feature enhances overall Wi-Fi performance by utilizing less crowded channels, resulting in a smoother experience for all connected devices.

Easy Setup & Management

Setting up the ASUS ZenWiFi AX (XT9) is simple and straightforward, even for those who are not tech-savvy.

The intuitive mobile app allows for easy installation, customization, and management of your home network.

Wi-Fi Data Rate

574 Mbps (2.4 GHz) + 2402 Mbps (5 GHz-1) + 4804 Mbps (5 GHz-2)

Product Segment

AX7800 ultimate AX performance

Transmit/Receive

2.4 GHz 2x2, 5 GHz-1 2x2, 5 GHz-2 4x4

Processor

1.7 GHz quad-core processor

Memory

256 MB Flash, 512 MB RAM

Operating Frequency Bands

2.4 GHz, 5 GHz-1, 5 GHz-2

Operating Modes

Wireless Router Mode, Access Point Mode

I/O Ports

1 x RJ45 for 2.5G BaseT WAN, 3 x RJ45 for Gigabit LAN, 1 x USB 3.2 Gen 1

Buttons

WPS Button, Reset Button, Power Switch

LED Indicators

Power x 1

Power Supply

AC Input: 110V240V (5060Hz), DC Output: 12 V with max. 3 A current

Package Content

ZenWiFi XT9, RJ-45 cable, Power adapter, Warranty card, Quick start guide

Dimensions

160 x 75 x 161.5 mm

Parental Controls

Time Scheduling, Safe Browsing, Customized Internet Schedule

Guest Network

Up to 9 guest network rules, Guest Network Time Limit

Security Features

WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise, WPS, Let's Encrypt, DNS-over-TLS, Firewall

VPN Support

Instant Guard, VPN Client L2TP, OpenVPN, PPTP, WireGuard, VPN Server IPSec, OpenVPN, PPTP, WireGuard, VPN Fusion

WAN Features

Dual WAN, DMZ, DDNS

LAN Features

IGMP Snooping, IPTV, LAN Link Aggregation, Wake on LAN (WOL)

Wireless Features

UTF-8 SSID, Wi-Fi MAC Address Filter, Wireless Scheduler, Airtime Fairness, RADIUS Client, Universal Beamforming, Explicit Beamforming
