GIGABYTE X870 GAMING WIFI6 AM5 DDR5 ATX Gaming Motherboard

GIGABYTE

GIGABYTE X870 GAMING WIFI6 AM5 DDR5 ATX Gaming Motherboard

Name: GIGABYTE X870 GAMING WIFI6 AM5 DDR5 ATX Gaming Motherboard
Brand: GIGABYTE
SKU: X870 GAMING WF6
Price: 75.0 KWD
Availability: InStock
Rating: 5.0 (10 reviews)

Product SKU: X870 GAMING WF6

Was :

75.000 KD

Quantity

Low stock

5 items in stock

In stock

Out of stock

Back in stock

Specifications
Description
Shipping Info

AMD Socket AM5: Supports AMD Ryzen 9000 / 8000 / 7000 Series Processors

Digital twin 8+2+2 phases VRM solution

Dual Channel DDR5: 4*DIMMs with AMD EXPO Memory Module Support

WIFI EZ-Plug: Quick and easy design for Wi-Fi antenna installation

EZ-Latch Plus: PCIe and M.2 slots with Quick Release & Screwless Design

EZ-Latch Click: M.2 heatsinks with screwless design

Friendly UI: Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW.

Ultra-Fast Storage: 3*M.2 slots, including 1* PCIe 5.0 x4

Efficient Thermal: VRM Thermal Armor Advanced & M.2 Thermal Guard

Fast Networking: 2.5GbE LAN & Wi-Fi 6 802.11ax

Extended Connectivity: Dual USB4 Type-C with DP-Alt, HDMI

X870 GAMING WIFI6

Specifications:

CPU	AMD Socket AM5, support for:
	AMD Ryzen™ 9000 Series Processors/
	AMD Ryzen™ 8000 Series Processors/
	AMD Ryzen™ 7000 Series Processors
Chipset	AMD X870
Memory	Support for DDR5 8200(OC)/8000(OC)/7800(OC)/7600(OC)/7200(OC)/7000(OC)/6800(OC)/6666(OC)/6600(OC)/6400(OC)/6200(OC)/ 6000(OC)/5600(OC)/5200/4800/4400 MT/s memory modules
	4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory
	Dual channel memory architecture
	Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
	Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules
	The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules
Onboard Graphics	Integrated Graphics Processor with AMD Radeon™ Graphics support+ASMedia USB4® Controller:
	- 2 x USB4® USB Type-C® ports, supporting USB4 and DisplayPort video outputs and a maximum resolution of 3840x2160@240 Hz
	* Support for DisplayPort 1.4 version and HDR.
	Integrated Graphics Processor with AMD Radeon™ Graphics support:
	- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
	* Support for HDMI 2.1 version, HDCP 2.3, and HDR.
	** Support native HDMI 2.1 TMDS compatible ports.
	(Graphics specifications may vary depending on CPU support.)
Audio	Realtek® Audio CODEC
	High Definition Audio
	2/4/5.1/7.1-channel
	* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
LAN	Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Wireless Communication module	Realtek® Wi-Fi 6 RTL8851BE (PCB rev. 1.0)
	- WIFI a, b, g, n, ac, ax, supporting 2.4/5 GHz carrier frequency bands
	- BLUETOOTH 5.3
	- Support for 11ax 80MHz wireless standard
	(Actual data rate may vary depending on environment and equipment.)
Expansion Slots	1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
	AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x16 mode
	AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode
	AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode
	* The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.
	Chipset:
	- 2 x PCI Express x16 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_1/2)
Storage Interface	1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs:
	AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs
	AMD Ryzen™ 8000 Series- Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
	AMD Ryzen™ 8000 Series- Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs
	1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3, M key, type 25110/22110/2580/2280 PCIe 4.0 x2 SSDs
	1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 25110/22110/2580/2280 PCIe 4.0 x4/x2 SSDs
	* The M2B_SB connector shares bandwidth with the M2C_SB connector. The M2C_SB connector will become unavailable when an PCIe 4.0 x4 SSD is installed in the M2B_SB connector.
	4 x SATA 6Gb/s connectors
	RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices
	* RAID 5 is only available on AMD Ryzen™ 9000 Series Processors.
	RAID 0, RAID 1, and RAID 10 support for SATA storage devices
USB	CPU+ASMedia USB4® controller:
	- 2 x USB4® USB Type-C® ports on the back panel
	CPU:
	- 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel
	- 1 x USB 3.2 Gen 1 port on the back panel
	Chipset+2 USB 2.0 Hubs:
	- 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
	Chipset:
	- 1 x USB Type-C® port with USB 3.2 Gen 2x2 support, available through the internal USB header
	- 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
	- 4 x USB 2.0/1.1 ports available through the internal USB headers
Internal I/O Connectors	1 x 24-pin ATX main power connector
	1 x 8-pin ATX 12V power connector
	1 x 4-pin ATX 12V power connector
	1 x CPU fan header
	1 x CPU fan/water cooling pump header
	4 x system fan headers
	3 x addressable RGB Gen2 LED strip headers
	1 x RGB LED strip header
	4 x SATA 6Gb/s connectors
	3 x M.2 Socket 3 connectors
	1 x front panel header
	1 x front panel audio header
	1 x USB Type-C® header, with USB 3.2 Gen 2x2 support
	1 x USB 3.2 Gen 1 header
	4 x USB 2.0/1.1 headers
	1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)
	1 x reset jumper
	1 x Clear CMOS jumper
Back Panel Connectors	1 x Q-Flash Plus button
	2 x SMA antenna connectors (2T2R)
	1 x HDMI port (Note)
	2 x USB4® USB Type-C® ports (DisplayPort (Note))
	1 x USB 3.2 Gen 2 Type-A port (red)
	3 x USB 3.2 Gen 1 ports
	4 x USB 2.0/1.1 ports
	1 x RJ-45 port
	3 x audio jacks
	(Note) Actual support may vary by CPU.
I/O Controller	iTE® I/O Controller Chip
H/W Monitoring	Voltage detection
	Temperature detection
	Fan speed detection
	Water cooling flow rate detection
	Fan fail warning
	Fan speed control
	* Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.
BIOS	1 x 256 Mbit flash
	Use of licensed AMI UEFI BIOS
	PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features	Support for GIGABYTE Control Center (GCC)
	* Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
	Support for Q-Flash
	Support for Q-Flash Plus
	Support for Smart Backup
Operating System	Support for Windows 11 64-bit
	Support for Windows 10 64-bit
Form Factor	ATX Form Factor; 30.5cm x 24.4cm
