Intel LGA 1200 socket: Ready for 11th and 10th Gen Intel Processors

Ultrafast connectivity: PCIe 4.0, 32Gbps M.2 slot, 1 Gb Ethernet and USB 3.2 Gen 1

Comprehensive cooling: PCH heatsink and Fan Xpert

5X Protection III: Multiple hardware safeguards for all-round protection

Asus PRIME H510M-K R2.0 M-ATX Gaming Motherboard

PRIME H510M-K R2.0

ASUS Prime series motherboards are expertly engineered to unleash the full potential of 11th and 10th Generation Intel® processors. Boasting a robust power design, comprehensive cooling solutions and intelligent tuning options, PRIME H510M-K R2.0 provides daily users and DIY PC builders a range of performance tuning options via intuitive software and firmware features.

Specifications:

Model	PRIME H510M-K R2.0
CPU	Intel® Socket LGA1200 for 11th Gen Intel® Core™, 10th Gen Intel® Core™, Pentium® Gold, and Celeron® Processors
	Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0
Chipset	Intel® H470 Chipset
Memory	2 x DIMM, Max. 64GB, DDR4 3200(OC)/3000(OC)/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory
	Dual Channel Memory Architecture
	Supports Intel® Extreme Memory Profile (XMP)
Graphics	1 x VGA port
	1 x HDMI™ port (Only Intel® 11th Gen processors support HDMI™ 2.1 with max. resolution of 4K@60Hz; others support HDMI™ 1.4 with max. resolution of 4K@30Hz)
Expansion Slots	1 x PCIe 4.0/3.0 x16 slot (Intel® 11th Gen processors support PCIe 4.0 x16; Intel® 10th Gen processors support PCIe 3.0 x16)
	1 x PCIe 3.0 x1 slot
Storage	1 x M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes)
	4 x SATA 6Gb/s ports
Ethernet	1 x Realtek 1Gb Ethernet
USB Ports	Rear USB (Total 6 ports):
	4 x USB 3.2 Gen 1 ports (4 x Type-A)
	2 x USB 2.0 ports (2 x Type-A)
	Front USB (Total 6 ports):
	1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports
	2 x USB 2.0 headers support 4 additional USB 2.0 ports
Audio	Realtek 7.1 Surround Sound High Definition Audio CODEC (supports Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192 kHz playback)
	Audio Features: Audio Shielding, Premium audio capacitors, Dedicated audio PCB layers
Back Panel I/O Ports	4 x USB 3.2 Gen 1 ports (4 x Type-A)
	2 x USB 2.0 ports (2 x Type-A)
	1 x VGA port
	1 x HDMI™ port
	1 x Realtek 1Gb Ethernet port
	3 x Audio jacks
	1 x PS/2 Keyboard/Mouse combo port
Internal I/O Connectors	1 x 4-pin CPU Fan header
	1 x 4-pin Chassis Fan header
	1 x 24-pin Main Power connector
	1 x 8-pin +12V Power connector
	1 x M.2 slot (Key M)
	4 x SATA 6Gb/s ports
	1 x USB 3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports
	2 x USB 2.0 headers support 4 additional USB 2.0 ports
	1 x RGB header
	1 x Clear CMOS header
	1 x COM Port header
	1 x Front Panel Audio header (AAFP)
	1 x S/PDIF Out header
	1 x Speaker header
	1 x SPI TPM header (14-1 pin)
	1 x 10-1 pin System Panel header
Special Features	ASUS 5X PROTECTION III (DIGI+ VRM, LANGuard, Overvoltage Protection, SafeSlot Core, Stainless-Steel Back I/O)
	ASUS Q-Design (Q-DIMM, Q-LED Core, Q-Slot)
	ASUS Thermal Solution (Aluminum heatsink design)
	ASUS Lighting Control (RGB header)
Software Features	ASUS Exclusive Software (Armoury Crate, AI Suite 3: TurboV EVO, EPU, DIGI+ VRM, Fan Xpert, EZ update)
	ASUS CPU-Z, Norton 360 Deluxe (60 Days Free Trial), WinRAR
	UEFI BIOS (ASUS EZ DIY: ASUS CrashFree BIOS 3, ASUS EZ Flash 3, ASUS UEFI BIOS EZ Mode)
BIOS	128 Mb Flash ROM, UEFI AMI BIOS
Manageability	WOL by PME, PXE
Accessories	Cables: 2 x SATA 6Gb/s cables
	Miscellaneous: 1 x I/O Shield, 1 x M.2 Anchor
	Documentation: 1 x User guide
Operating System	Windows® 10 64-bit
Form Factor	micro-ATX Form Factor (8.9 inch x 8.0 inch / 22.6 cm x 20.3 cm)
