MSI PRO B760M-A WIFI DDR5 mATX Gaming Motherboard

MSI

MSI PRO B760M-A WIFI DDR5 mATX Gaming Motherboard

Name: MSI PRO B760M-A WIFI DDR5 mATX Gaming Motherboard
Brand: MSI
SKU: 911-7D99-035
Price: 59.0 KWD
Availability: OutOfStock
Rating: 5.0 (10 reviews)

كود المنتج: 911-7D99-035

السعر قبل :

59.000 KD

كمية

مخزون منخفض

0 عنصر في المخزون

في المخزن

إنتهى من المخزن

مرة أخرى في المخزون

الخصائص
وصف
معلومات الشحن

Support Intel Core 14th/ 13th/ 12th Gen Processors, Intel Pentium Gold and Celeron Processors for LGA 1700 socket.

Supports DDR5 Memory, Dual Channel DDR5 6800+MHz (OC)

Enhanced Power Design: 12+1 Duet Rail Power System with P-PAK, 8-pin + 4-pin CPU power connectors, Core Boost, Memory Boost

Premium Thermal Solution: Extended Heatsink, MOSFET thermal pads rated for 7W/mK and additional choke thermal pads are built for high performance system and non-stop gaming experience

High Quality PCB: 6-layer PCB made by 2oz thickened copper.

Lightning-Fast Game experience: PCIe 4.0 slot, Lightning Gen 4 x4 M.2

Intel Turbo USB 3.2 Gen 2: Powered by Intel USB 3.2 Gen2 controller, Turbo USB ensures an uninterrupted connection with more stability and fastest USB speeds.

2.5G LAN with Wi-Fi 6E Solution: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection.

AUDIO BOOST: Reward your ears with studio grade sound quality for the most immersive gaming experience.

MSI PRO B760M-A WIFI M-ATX Gaming Mother Board

Specifications:

Chipset	INTEL B760
CPU	Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors
	LGA 1700
Memory	4x DDR5, Maximum Memory Capacity 192GB
	Memory Support DDR5 6800+(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz
	Max. overclocking frequency:
	• 1DPC 1R Max speed up to 6800+ MHz
	• 1DPC 2R Max speed up to 6400+ MHz
	• 2DPC 1R Max speed up to 6000+ MHz
	• 2DPC 2R Max speed up to 5600+ MHz
	Supports Intel® XMP 3.0 OC
	Supports Dual-Controller Dual-Channel mode
	Supports non-ECC, un-buffered memory
Onboard Graphics	2x HDMI™
	Support HDMI™ 2.1, maximum resolution of 4K 60Hz*
	2x DisplayPort
	Support DP 1.4, maximum resolution of 4K 60Hz*
	*Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.
Slot	2x PCI-E x16 slot
	1x PCI-E x1 slot
	PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)
	PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
	PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)
Storage	2x M.2
	M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices
	M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices
	4x SATA 6G
	* SATA8 will be unavailable when installing M.2 SATA SSD in the M2_2 slot.
Raid	Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
USB	2x USB 2.0 (Rear)
	4x USB 2.0 (Front)
	2x USB 3.2 Gen1 Type A (Rear)
	4x USB 3.2 Gen1 Type A (Front)
	1x USB 3.2 Gen1 Type C (Front)
	2x USB 3.2 Gen2 Type A (Rear)
LAN	Realtek® RTL8125BG 2.5G LAN
Wireless LAN & Bluetooth	Intel® Wi-Fi 6E
	The Wireless module is pre-installed in the M.2 (Key-E) slot
	Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps
	Supports 802.11 a/ b/ g/ n/ ac/ ax
	Supports Bluetooth® 5.3, FIPS, FISMA
	* Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in Windows 11.
	** Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11.
Audio	Realtek® ALC897 Codec
	7.1-Channel High Definition Audio
Internal I/O	1x Power Connector(ATX_PWR)
	2x Power Connector(CPU_PWR)
	1x CPU Fan
	1x Pump Fan
	2x System Fan
	2x Front Panel (JFP)
	1x Chassis Intrusion (JCI)
	1x Front Audio (JAUD)
	1x Com Port (JCOM)
	2x Addressable V2 RGB LED connector (JARGB_V2)
	1x RGB LED connector(JRGB)
	1x TPM pin header(Support TPM 2.0)
	4x USB 2.0 ports
	4x USB 3.2 Gen1 Type A ports
	1x USB 3.2 Gen1 Type C ports
LED Feature	4x EZ Debug LED

خدمات التوصيل المتاحة في الكويت:

١. التوصيل خلال ٢٩ دقيقة - 5 دينار كويتي

٢. ألترا إكسبريس (توصيل خلال ساعة واحدة) - ٤.٥ دينار كويتي

٣. سوبر إكسبريس (توصيل خلال ساعتين) - ٢.٥ دينار كويتي

٤. التوصيل السريع (توصيل خلال ٤ ساعات) - 2 دينار كويتي

٥. التوصيل في نفس اليوم (توصيل خلال ٢٤ ساعة) - ١.٥ دينار كويتي

٦. التوصيل في اليوم التالي - 1 دينار كويتي

٧. التوصيل خلال يومي عمل - 1 دينار كويتي

ملاحظة: خدمة التوصيل السريع متاحة في مناطق محددة ووقت محدد. خيار التوصيل المتاح سيكون واضحًا عند إتمام عملية الشراء.

تسجيل الدخول

MSI PRO B760M-A WIFI DDR5 mATX Gaming Motherboard

شارك هذا المنتج

MSI PRO B760M-A WIFI M-ATX Gaming Mother Board

Specifications:

Chipset

INTEL B760

CPU

Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors

LGA 1700

Memory

4x DDR5, Maximum Memory Capacity 192GB

Memory Support DDR5 6800+(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz

Max. overclocking frequency:

• 1DPC 1R Max speed up to 6800+ MHz

• 1DPC 2R Max speed up to 6400+ MHz

• 2DPC 1R Max speed up to 6000+ MHz

• 2DPC 2R Max speed up to 5600+ MHz

Supports Intel® XMP 3.0 OC

Supports Dual-Controller Dual-Channel mode

Supports non-ECC, un-buffered memory

Onboard Graphics

2x HDMI™

Support HDMI™ 2.1, maximum resolution of 4K 60Hz*
